The Abrasiguard AA-Series Polyurethane-Lined Pipe is a straight length of pipe spool using the Abrasiguard AX-100 high-performance internal lining. This premium polymer can handle very high slurry velocities, turbulent and non-turbulent slurry regimes, and small and large particle slurry. It withstands erosive wear in straight piping geometries.

The chemically bonded liner offers a wide temperature range, very high hydrolysis resistance, chemical compatibility with most fluids, and very low friction loss coefficient. It also doesn’t require any corrosion allowance as it’s not affected by dissolved oxygen in the carrier fluid.

The Abrasiguard AA-Series pipe spool is used for slurry transfer in mineral processing plants, concentrate pipelines, tailings pipelines, oil sands pipelines, and dredging. It’s also used to transfer fluids that require an internal corrosion liner.

Innovative piping, proven results. Learn how we make it here »

Technical specifications

Brand

Abrasiguard

Model

AA-Series

Pipe size

DN50–1350 (2–54”) as standard
Non-standard sizes available (where required to optimise hydraulic performance)

Pipe length

0.1m (4”) to 18m (60’) as standard

Design codes

Standard: ASME B31.3, ASME B31.4, AS4041
Contact us for other requirements

Pipe types

SMLS, ERW, LSAW, DSAW, SSAW/HSAW

Pipe specifications

Standard: API 5L, ASTM A53/A106, API 5CT, ASME B16.9
Contact us for other requirements

Pressure rating

As per design code

Temperature rating

Based on internal lining system selected

End connections

Plain end
Flanged (fixed or swivel)
Grooved (roll or cut)
Threaded
Fully welded
Custom

Flange types

AS2129, ASME B16.5, ASME B16.47, AWWA C207, AS4087, BS EN 1092, BS3293, JIS B2220, SANS 1123, DIN ISO 7005, custom

Groove types

AWWA C606 OGS, Victaulic AGS, custom or special

Thread types

BSP, NPT, API, premium, custom

Extra options

Custom nozzles, branches, or connections
Wear monitoring system (plug-only or push-button)

Material specifications

Pipe material

Carbon steel (all grades)
Stainless steel (SS304, SS316)
Exotic alloy

External coating

Uncoated
Zinc or zinc-aluminium primer
Epoxy based (single or multi-layer)
Polyurethane based (single or multi-layer)
Custom system

Internal lining specifications

AX-100 high-performance polyurethane

High-performance polyurethane liner system
Suitable for turbulent and non-turbulent slurry regimes
Suitable for small and large particle slurry types
Suitable for slurry velocities to 10m/s as standard
Suitable for straights (low 0–10° imp. angle wear)
Suitable for bends/fittings (medium 10–45° impingement angle wear)
Strong adhesion to substrate (chemically bonded)
Suitable for long-term immersion (hydrolysis-resistant)
Compatible with most carrier fluids and reagents (consult factory for chemical compatibility with specific media)
Very low wet friction coefficient (very low surface roughness)
Resistant to dissolved oxygen (nil corrosion allowance required)
Temperature range (wet): +20 to +40°C (transient to +60°C)
Temperature range (dry): 0 to +60°C (transient to +80°C)

AX-100XT high-performance polyurethane (XT upgrade)

Same as AX-100, with additional upgrades
Upgrade: Enhanced temperature range
Upgrade: Enhanced adhesion (corrosive and/or high temperature)
Upgrade: Enhanced resistance to “cold wall” effect
Upgrade: Enhanced resistance to long-term immersion
Temperature range (wet): 0 to +65°C (transient to +85°C)
Temperature range (dry): -60 to +80°C (transient to +120°C)
